PCB Prototype the Easy Way

Full feature custom PCB prototype service.

Do you want to test your design with this material? Hurry up and upload your part for inquiry
Request Quotes
Build Time: 2-3 Business Days
4.9 (61 Reviews) 2679 orders
Material type: Plastic
ABS is a common thermoplastic with good mechanical properties and excellent impact strength, superior to PLA but with less defined details.
Process compatibility
Material Color
Silver gray
Material advantages
It has good impact resistance and heat resistance, low temperature resistance, chemical resistance and excellent electrical properties. It also has the characteristics of easy processing, stable product size, and good surface gloss.
Material shortcomings
The bending strength and compression strength are poor, and the mechanical properties are greatly affected by temperature.
Recommended description
It is easy to paint and color, and it can also be surfaced secondary processing such as metal spraying, electroplating, welding, hot pressing and bonding.
Tensile strength 4,100psi
Flexural modulus 304,000psi
Izod impact (notched) 7.7ft-lbs/in of notch
Heat deflection temperature @ 264 psi 177°F
Maximum continuous service temperature in air 160°F
Water absorption (immersion 24 hours) 0.30%
Coefficient of linear thermal expansion 5.6in/in/°Fx10^-5
Common applications
• Automotive applications
• Instrument panels
• Pillar trim
• Door liners and handles
Get your parts into production today
Get an instant quote
