Thick gold semiconductor test PCB

Applications
Semiconductor test
Features
/
Material
S1000-2M
Layers
16 Layers
Thickness
6.5mm±0.3mm
Min Hole Size
Mechanical hole 0.2mm
Min Track/Spacingh
250/250um
Minimum board thickness and hole ratio
14:1
Surface Finish
Immersion gold(ENIG) 0.05um
Calculer
Détails du produit

Thick gold semiconductor test PCB boards are mainly used in the field of semiconductor testing. It has a 16-layer structure and uses Shengyi S1000-2M material. The entire board is plated with thick gold.


Related Products Afficher plus >>
  • Semiconductor test PCB

    8 layers, Material: S1000-2M, Thickness: 4.4±0.4mm
