Ultra-high speed PCB gold finger board

Produits de PCB / High frequency and high speed PCB / Ultra-high speed PCB gold finger board

Passez la souris dessus pour zoomer

Applications

High-speed computer board

Features

Material

TU-872SLK+RO4350b

Layers

16 Layers

Thickness

1.8±0.1mm

Min Hole Size

Mechanical hole 0.20mm

Min Track/Spacingh

75/75um

Minimum board thickness and hole ratio

9:1

Surface Finish

Golden finger 30"+Immersion gold(ENIG) 2u"

Calculer

Détails du produit

Ultra-high-speed PCB gold finger board, this type of circuit board is made of Taiyao TU-872SLK + Rogers RO4350b high-speed material, produced by mixed pressure, high-end CNC mechanical drilling, surface immersion gold, gold finger thick gold plating and other processes, the smallest The aperture can reach 0.2mm, the Min Track/Spacing can reach 127/75um, and the gold-plated thickness of the gold finger can reach 30u. This type of high-speed PCBis widely used in the field of high-speed computer boards.
